- Aluminum Surface Color: Customized RAL color.
- Thickness: 20mm. (Customized 10~120mm)
- Width: Maximum 2.6m.
- Length: Max 12m.
- Top Layer: 1.0mm aluminum sheet + 0.7mm CFRT sheet.
- Core: 80kg/m³ polypropylene honeycomb. (Customized: 60~160kg/m³)
- Bottom Layer: 0.7mm CFRT sheet.
Description
Thermoplastic polypropylene honeycomb panels can be combined with any material using adhesives, and the combination is stable and reliable. Adding a layer of pre-coated aluminum sheet to the surface of the honeycomb panel can increase the compressive and flexural strength and increase the safety factor. The PVDF coating prepainted aluminum surface has rich decorative effects.
Application Areas
RV wall panels, dry freight truck wall panels, building exterior wall panels, building interior partitions, door panels, etc.
